Nanchang Metro Line 1 – Track Mats for FST

Nanchang Metro Line 1 -
Track Mats for FST

project details
Track Mats for FST
Nanchang Metro Line 1

Description

Nanchang Metro Line 1, the first subway line in Nanchang, Jiangxi Province, China has a total length of approx. 28. kilometres. The entire Metro line and its 24 stations are underground.

Solution

More than 140 sites were detected as sensitive areas in terms of ground-borne noise and vibration. A request was made for the installation of FST on highly resilient track mats. Tiantie delivered the track mat USM 1000 W with a very low stiffness to meet the required mitigation measures. Approval measurements have shown an efficiency of 19 dB in higher 1/3 octave bands.

requirements
reduction of train-induced
vibrations through the installation of track mats

NR, CR, SBR

Material

80 km/h

Design speed

2014/9 – 2015/1

Installation

Bored tunnel

Tunnel type

14 T

Axle load

520 m

Installed length

USM 1000W
USM 2030

Product details

impressions
visible
results
tiantie-group_cases_nanchang-metro-line1-viaduct_image03
tiantie-group_cases_nanchang-metro-line1-viaduct_image02
