Shanghai Metro Line 16 – Track Mats for FST

Shanghai Metro Line 16 -
Track Mats for FST

project details
Track Mats for FST
Shanghai Metro Line 16

Description

Shanghai Metro Line 16 is one of the four city lines that constitute the main skeleton of the Shanghai rail transit network.

Solution

Track mats were installed in the turnout area before the station reducing the vibration and noise impact of the trains entering and leaving Longyang Road station. Approval measurements have shown an insertion loss of about 13 dB in the frequency range of 63 Hz to 125 Hz.

requirements
vibration mitigation of turnout
impacts through installation of an FST on track mats

NR, CR, SBR

Material

120 km/h

Design speed

2012/3 – 2013/3

Installation

16 T

Axle load

124 m

Installed length

USM 1000W
USM 2030

Product details

impressions
visible
results
tiantie-group_cases_shanghai-metro-line-16-tunrout-section_image01
tiantie-group_cases_shanghai-metro-line-16-tunrout-section_image02
tiantie-group_cases_shanghai-metro-line-16-tunrout-section_image03
